XK - 9015 heavy stone engraving machine

XK - 9015 heavy stone engraving machine

  • Min.Order Quantity: 1 Set
  • Supply Ability: 100 Sets per Month
  • Port: qingdao
  • Payment Terms: L/C,T/T
Get Latest Price:
  • *Quantity: Set/Sets
Verified Supplier JINANXUNKECNCMACHIBERY.Co
| Factory
Experience:2015-05-22
Buyer Protection

- Guaranteed Secure Payments on Every Order

- Refund if your item is not delivered or as described

- Buyer Protection after order confirmation

Latest Browsing
Product Details
  • Place of Origin:  jinan
  • Brand Name:  xunke
  • Model Number:  XK - 9015

Application industry

Natural marble, granite, artificial stone, tombstone, milestone, ceramic tile, glass and other materials of three-dimensional relief and line carve, cutting, edge, drilling two-dimensional carving

Product feature

Lathe bed with thick wall steel pipe welded together, after the high temperature tempering treatment, ensure a little deformation, good rigidity and strength.

Y axis adopt double motor drive, selection of matching, to ensure the smooth movement.

Mixer adopts high precision gear rack transmission, high precision, speed and strength.

Mixer adopts imported square linear guide, precision is high, bearing large redundancy, long service life.

Electromechanical provided design, selection of all kinds of electrical accessories, minimize failure rate.

Mixer machine equipped with water tank and automatic water cooling system.

In pieces all the dust waterproof design, all-round protection machine transmission parts.

Technical parameters

Machine type XK - 9015 heavy stone engraving machine
Work schedule 900 * 1500 * 300

Machine structure of thick wall tube structure of lathe bed, lu: xingcai mesa

The machine size 1800 * 2450 * 1800 (mm)

Engraving depth (300 mm)

The maximum speed carving 20 m/min

The machining accuracy < 0.05/300 mm

Carving instruction G code

Spindle power 5.5 kw water-cooled spindle

Cutter diameter   Φ Φ 6 Φ 12.7 3.175

XYZ guide   Three axis square linear guide

XY high precision rack gear transmission mode; The Z axis high precision ball screw drive

Working voltage AC380V, 50 hz

The operating system d macro system/DSP or specified system

Fixed clamp fixed materials


  • Place of Origin:  jinan
  • Brand Name:  xunke
  • Model Number:  XK - 9015
